FYF20B

FYF20B

Underground means damp, dust, tight spaces — plus firedamp and coal dust risks. The FYF20B is born for this. It is an intrinsically safe mining transmitter with Ex ia I Ma marking, a flame-retardant conductive housing and IP67 protection. 21 buttons cover the many motions of underground machines, and the 2.5-inch display stays readable in dark tunnels. The working range is designed above 20 m by mine-safety rules, keeping the operator in a supported, safe area. Optional RFID card and 3-axis sensor: the machine starts only for the right person, and stops on a fall.Key Features
  • Mining intrinsically safe design, Ex ia I Ma — KA, CCC and Ex certificates all in hand
  • Flame-retardant conductive housing, IP67 — made for harsh underground conditions
  • 21 buttons plus a 2.5-inch display — full control of multi-motion machines
  • 4 V / 1850 mAh Ex lithium pack (LiFePO4, potted protection)
  • Optional RFID card and 3-axis sensor — authorised start, stop on fall or abnormal tilt
Options & Configurations
  • RFID identification card (operator authorisation)
  • 3-axis sensor (fall, impact and abnormal tilt detection)
  • Button functions and panel labels set for your mining machine
  • Receiver and outputs configured per project
Certifications
  • Mining Safety Mark (KA): No. KFH220012, valid until 2027-10-31 (metal and non-metal mines)
  • CCC certificate No. 2023322304004990, valid until 2028-01-08
  • Explosion-proof certificate No. SHExC22.1869, Ex ia I Ma, valid until 2027-10-08
  • Standards: GB/T 3836.1-2021, GB/T 3836.4-2021, MT/T 1137-2011
  • Note: charge and replace the battery only in a safe area
SeriesMine Explosion-proof FYF Series
ModelFYF20B
Size240×68×54 mm
Weight (excluding battery)0.35kg
MaterialFlame-Retardant Conductive Engineering Plastics
Protection ClassIP67
Power Supply7.4VDC/1850mAh
Wireless Range≥20m
Operating Current80mA
Transmit Power≤10mW
Frequency Range433 MHz Band: 427.000–436.300 MHz
470 MHz Band: 472.350–485.775 MHz
Antenna Typebuilt-in
Operating Temperature RangeTemperature: -25°C to 70°C
Humidity: 0% to 97% RH (non-condensing)
Optional FeaturesIdentification Card, 3-Axis Sensor
Transmitter Operation ModesButton-operated
Explosion Protection TypeIntrinsically Safe
Explosion-proof MarkEx ia I Ma
Display2.5″
Applicable StandardsGB/T 3836.1-2021 *Explosive atmospheres — Part 1: Equipment — General requirements*
GB/T 3836.4-2021 *Explosive atmospheres — Part 4: Equipment protected by intrinsic safety “i”* MT/T 1137-2011 *General technical specifications for mining infrared remote controllers*
Dimensional Drawing



Frequently Asked Questions

Please contact our team for the current lead time for your selected model and configuration. Include your order quantity, customization requirements, delivery destination, and required arrival date so we can assess your project schedule.

Yes. Techwell offers international delivery with shipment tracking. Please provide your delivery destination when requesting a quote so our team can discuss shipping arrangements for your order.



Yes. Techwell offers OEM/ODM services for industrial remote control applications. Depending on the selected model, customization options may include control layouts, frequency configuration, display options, and receiver compatibility. Contact our engineering team to confirm the options available for your equipment.



Please share the product model you are interested in, your equipment type, required control functions, order quantity, and destination country. If you need a customized configuration, include your technical requirements so our team can assess the application and prepare a suitable proposal.

Techwell provides technical support, user manuals, and programming software for its remote control systems. Contact our team for the documentation and assistance relevant to your selected model and configuration.
