SES08

SES08

The Super Series is our platform line for global markets: one design language, one operating logic across all sizes. The SES08 is the 8-button single-speed model, with a large data display and an A / BA+B selector at the bottom for quick hoist combination switching. The unit is CE certified, and SIL 2 / PL d functional safety is available as an option — a complete package for machines built for export.Key Features
  • CE certified for easy export (SIL 2 / PL d functional safety optional)
  • Large display for channel, battery, signal and machine status at a glance
  • A / BA+B selector at the base for fast single / double hoist switching
  • 8 single-speed buttons in clear zones — no training needed
  • 150 m+ range, IP66, -25 ℃ to +70 ℃, AA or lithium power
Options & Configurations
  • SIL 2 / PL d functional-safety version (function code 800)
  • Display content, button functions and panel labels set for your market
  • Button indicator lights and buzzer feedback
  • AA battery version or 4.2 V rechargeable lithium version
Certifications
  • CE certified
  • Optional: SIL 2 / PL d functional safety
Industrial Remote Control EnclosureSPS08
Dimensions227 × 75 × 50 mm
Weight (excl. battery)0.36 kg
No. of Buttons8
MaterialEngineering Plastic
Ingress ProtectionIP66
Button TypeSingle-speed / Dual-speed
Power Supply2 × AA batteries (3V) / Rechargeable Li-ion battery (4.2V)
Wireless Range≥ 150 m
Current ConsumptionStandby: 5 μA; Average: 10 mA
Transmit Power10 mW
Frequency Range429 MHz – 459 MHz
AntennaInternal
Operating ConditionsTemperature: -25°C to 70°C; Humidity: 0% – 97% RH (non-condensing)
Optional Add-onsDisplay, Indicator Light(s)
SPT100 remote control Engineering View of External Dimensions



Frequently Asked Questions

Please contact our team for the current lead time for your selected model and configuration. Include your order quantity, customization requirements, delivery destination, and required arrival date so we can assess your project schedule.

Yes. Techwell offers international delivery with shipment tracking. Please provide your delivery destination when requesting a quote so our team can discuss shipping arrangements for your order.



Yes. Techwell offers OEM/ODM services for industrial remote control applications. Depending on the selected model, customization options may include control layouts, frequency configuration, display options, and receiver compatibility. Contact our engineering team to confirm the options available for your equipment.



Please share the product model you are interested in, your equipment type, required control functions, order quantity, and destination country. If you need a customized configuration, include your technical requirements so our team can assess the application and prepare a suitable proposal.

Techwell provides technical support, user manuals, and programming software for its remote control systems. Contact our team for the documentation and assistance relevant to your selected model and configuration.
