In addition to basic digital I/O, PWM, and serial buses, the Techwell ML300 industrial remote control receiver also supports industrial Ethernet buses such as DP, PN, EtherNet/IP, and Modbus TCP. You can also configure the protocol parameters for this remote control receiver on-site via the on-screen menu.
| Series | M-Series Receiver |
| Model | MLN Series |
| Size | 320×210×133mm |
| Weight | 3.2kg |
| Material | Engineering Plastics |
| Protection Class | IP65 |
| Power Supply | 12-30VDC、42-250VAC、380VAC |
| Operating Current | 150mA |
| Rated Power | ＜10W |
| Electric Shock Capacity | 8A/250VAC |
| Antenna Type | External |
| Operating Temperature Range | -25℃-70℃ |
| Output Method | CANOPEN、PWM信号、I/O信号、AO信号 |
| Output Interface | HAN32或HAN64 |
| Optional Features | Feedback Detection, Audible and Visual Alarms, Data Card |
| Safety Standards | EN ISO 13849-1:2015 PL d |
| Dimensional Drawing |  |
Tell us about your machinery and requirements. Our engineering team will respond within 24 hours with a customized solution and pricing.
